High-Efficiency Pert Continuous Flexible Insulated Pipe Production Line

Name: HighEfficiency Pert Continuous Flexible Insulated Pipe Production Line
Brand: Huashida
Price: 70 USD

Quality High-Efficiency Pert Continuous Flexible Insulated Pipe Production Line for sale

Apply to : Pert Flexible Insulation Pipes and Pert Rigid Insulation

Packaging Details : Standard Packing

Price : US$70,000.00-300,000.00

Payment Terms : T/T

Delivery Time : 60days

Brand Name : Huashida

Place of Origin : China

Pipe Usage : Sdistrict Heat/Chiller Supply

Certification : CE, Rohs，TUV

MOQ : 1

Supply Ability : 30 Unit/Year

Model Number : 20-350MM

Inner Pipe : PE-Xa or PE-Rt II Material

Foaming Layer : Soft Polyurethane Foam and Rigid Polyurethane Foam

Contact Now

High-Efficiency Pert Continuous Flexible Insulated Pipe Production Line

Continue Pert Flexible Insulated Pipe Production Line.

The one-step method is an advanced and newly developed production technology. It can be used for both flexible hose insulation and rigid pipe insulation. Nevertheless, ordinary extrusion equipment fails to meet the production requirements of one-step PERT insulated pipes. Therefore, customized design is required for the extruder screw & barrel, pipe mould, sizing unit and cooling system.

In just two years, Huashida has conquered 130 technical difficulties and developed China’s first self-developed one-step PERT insulation pipe production line with complete independent intellectual property rights.

In addition, Huashida has rolled out standard PERT insulated pipes and fiber-reinforced PERT insulated pipes. According to structural shape and service performance, these products are divided into flat-wall insulated pipes and corrugated insulated pipes.

Key Benefits	Description
Lightweight Design	Lightweight structure for easy transportation, installation, and handling, while reducing labor costs.
Excellent Flexibility	Fewer pipe joints and outstanding flexibility improve installation efficiency and system reliability.
Superior Thermal Insulation	Polyurethane foam insulation with thermal conductivity as low as 0.013 W/(m·K), providing 4–9 times better insulation performance than conventional materials.
Long Service Life	A closed-cell rate of up to 92% ensures excellent insulation performance and a service life of more than 50 years.
Outstanding Corrosion Resistance	The tightly bonded PU foam layer effectively isolates moisture and air, protecting the pipeline from corrosion even in harsh environments.
Cost Efficiency	Reduces excavation costs by up to 50%, lowers civil construction costs by up to 90%, and shortens project installation time significantly.
Energy Saving	Excellent thermal performance minimizes heat loss and helps reduce long-term operating costs.
Eco-Friendly Solution	Requires less installation space, generates minimal production waste, and supports sustainable, environmentally friendly construction.

The flexible pre-insulated pipes production line consists of the following components:

1) Production line for inner pressure pipe (PERT, PEX)
2) Inner pipe unwinding device
3) Pipe feeding device
4) Conveyor
5) Pipe centering device
6) Preheating and temperature control
7) Film feeding device
8) High-precision foaming machine
9) Forming machine with temperature control
6) Extruder for casing pipe and water cooling
7) Pull-off device
8) Winding machine

Can be customized production.Meet different customer requirements, lifetime technical support and maintenance services.

District heating and cooling networks
Residential and commercial building pipelines
Industrial piping systems
Transportation of hot and cold fluids
